Beskrivelse
Features
•Routes and controls program from multiple sources to up to five zones
•Left and right sets of balanced source 1 & 2 inputs can also accept a mono signal source
•Source 1 & 2 input channels are internally routed to the five zones
•Each zone features source 1 & 2 level controls and balanced L/R outputs
•Stereo/Mono selector button on each zone
•Signal/Clip/Mono LED indicators on front panel for each zone
Specifications
•Input Impedance: 45.1K Ohm
•Max. Input Level: 9 dBV
•Max. Gain: +15 dB
•Output Level: 22 dBV
•THD: 0.2%
•Dimensions: 483 mm(W) x 126 mm(D) x 44 mm(H)
•Weight:3.3Kgs
